PRODUCT FUNCTION
-
Energy management
By real-time monitoring of power load, analyzing energy consumption, energy-saving suggestions and o
-
Early warning and alarm
Continuously monitor the status of the power system. Once a fault or anomaly is detected, an alarm w
-
Remote control
Supports remote control. Users can access the platform system at any time through mobile devices or
-
Flexible connection with third parties
Support third-party integration; Support remote and batch management of MQTT addresses
-
Powerful edge computing capabilities
Supports edge computing and has built-in AI models; Support OTA upgrade
-
Electric energy metering
The bidirectional electric energy metering accuracy is grade 1 and supports fee control metering
Performance Parameter
| Model | SMCT DT3 4G |
| Electrical characteristics | |
| Main control power supply method | AC 220V单相供电 |
| Rated frequency | 50/60Hz |
| The scope of PT work | 85-265V |
| CT input range | （Direct）5~80A；（Second time）5A |
| CT form | External,open type/tube type |
| Other features | |
| Working environment temperature | -20℃~+70℃ |
| Working relative humidity | ≤95%(No condensation) |
| Standby power consumption | ＜0.5W（With gateway）；＜1W（With gateway） |
| Installation method | Standard guide rail installation |
Product Advantages
-
-
控制响应快
实时快速响应的协调控制，实现数据准确性、即时性
-
-
同步精度高
功率采样精度≦0.1%，电能采样精度0.5级
-
-
广域同步采样
支持多设备同步采样，广域同步采样精度≦10毫秒
Application Scenarios
-
Community
Monitoring of electric bike charging at homeElectrical fire hazard monitoringFire emergency intermodal monitoring -
School
Supervision of illegal electrical appliances in dormitoriesManagement of energy-saving electricity usage in public areasFire emergency protection in colleges and universities -
Commercial
Monitoring of safety hazards in commercial electricity usageRemote merchant electricity usage managementEnergy conservation in public areas of shopping malls -
Logistics
Energy conservation management for warehouse consumptionSafety charging monitoring for express delivery electric vehiclesCircuit aging safety warning -
Park
Energy conservation management in public areas of the parkEfficient and rapid power restoration and closingSafety monitoring of potential hazards -
Shop
Store electrical safety monitoringIdentification of high-power malignant loadsFire prevention and early warning management
